Mercury CEM Sample Conditioner

MAKER Tekran (Canada)
MODEL 3300Xi_Mercury CEMS
Application Coal fired power plants / Speciation studies / Waste incinerators / Bench scale testing / Other indu
Parameter Mercury
Product Detail

▷Specification



◼ Parameter: Mercury

◼ Detection limit: < 0.05 ㎍/㎥

◼ Measurement time: 2.5 min

◼ Elemental Mercury Calibration Unit (Model 3310)

Output concentration range: 0.5 - 1900 ug/m

Allowable ambient temp: +5 to +40 °C

Calibration gas delivery rate: 2 - 30 SLPM

Hg source control range: +5.00 to +50.00 °C

◼ Ionic Mercury Calibration Unit (Pat Pend) (Model 3315)

Output concentration range: 0.5 - 100 ㎍/㎥

Calibration gas delivery rate: 2 - 30 SLPM

Period of Hg2+ standard: 3 – 12 months

Hg source control range: Works with M3310

◼ Mercury CEM Sample Conditioner (Model 3320)

Detection range: 0.05 - 1500 ㎍/㎥(Note 1)

Update: every 2.5 min



▷Features



◼ Patented mercury speciation technology to determine elemental, ionic and total mercury

◼ Unaffected by SO2, NOX, CO, HCl and all other common combustion by-products

◼ Interfering acid gases removed without chemical reagents or solid sorbents

◼ Provides real-time feedback for mercury control technology optimization

◼ Detection limit of 0.01 ug/m3 as determined by EERC/ICCI independent study

◼ Low-cost calibration eliminates expensive mercury calibration gas cylinders

◼ No chemical reagents required



▷Applications



Coal fired power plants / Speciation studies / Waste incinerators / Bench scale testing / Other industrial sources / Mercury removal process monitoring
