Specification

◼ > 95%의 5 nm ~ 2.5 µm dry collection

◼ > 90%의 5 nm ~ 10 µm wet collection

◼ Dry and liquid Collection

◼ Minimal heating of the airflow minimizes loss of volatile constituents, reduces thermal decomposition, and maintains microorganism viability

◼ Flow rate : 1.0 ~ 1.5L/min

◼ 500 mm x 305 mm x 255 mm, 6.8kg

◼ Environmental operation conditions : 10 ~ 35°C, 10 ~ 95% RH

Features

◼ High particle collection efficiency with no particle bounce

◼ >95% from 5 nm to 2.5 μm for dry collection; >90% up to 10 μm for liquid collection

◼ Minimal heating of the airflow minimizes loss of volatile constituents, reduces

thermal decomposition, and maintains microorganism viability

◼ Uninterrupted, time-resolved sampling from minutes to hours

◼ Concentrated sample deposition improves analysis sensitivity (LOD/LOQ)

◼ Automation of sample handling eliminates tedious and time consuming sample prep
